CK6140 Horizontal CNC lathe
This machine tool can automatically complete the cutting process of cylindrical surface, conical surface, arc surface, end surface, grooving, chamfering and other processes for various shafts and chucks, and can perform straight thread, taper thread and other threads It is especially suitable for mass production of parts in general machinery manufacturing industry, especially for complex and high-precision parts, and is also suitable for tool manufacturing industry and education and teaching departments.
The guide rail of the machine tool is hardened and finely ground by audio frequency, with good wear resistance and high precision;
The main shaft adopts single-spindle frequency conversion and speed change; two shafts and two gears frequency conversion and speed change;
The machine tool is equipped with an automatic lubrication system, which can effectively reduce the influence of thermal changes and ensure machining accuracy;
The machine tool can be equipped with CNC operating systems such as Guangshu, Siemens, and Fanuc, which have reliable controllability;
Special accessories such as pneumatic chucks and hydraulic chucks can be added according to user requirements.
| Specifications | 单位 | CK6130 | CK6140 |
| Max.swing over bed | mm | 300 | 400 |
| Max. swing over cross slide | mm | 100 | 240 |
| Max.processing length | mm | chuck卡盘200/夹头chuck head320 | chuck卡盘420/680 |
| X/Z axis travel | mm | 300/350 | X：280Z:550/750 |
| Spindle nose | A2-5 | A2-6/（A2-8可选） | |
| Spindle bore | mm | 48 | 48/82 |
| Bar capacity | mm | 40 | 40/65 |
| Max. spindle speeo | rpm | 2500 | 150-2000/150-1800 |
| Chuck size | mm | 160 | 200/250 |
| Spindle motor | kW | 4 | 5.5/7.5（可选） |
| X/Z axis repeatability | mm | ±0.005 | ±0.005 |
| X/Z axis feed motor torque | N.m | X:4Z:4 | X:4Z:6 |
| X/Z Rapid traverse | m/min | X:6Z:8 | X:6 Z:8 |
| Tailstock quill dia | mm | D52 | 中60 |
| Quill traverse | mm | 90 | 100 |
| Quill taper | # | MT4 | MT4 |
| Turret type | 4工位电动刀架 | 4工位电动刀架 | |
| Cutting tool size | mm | 20×20 | 20×20 |
| Guide way type | 双山 | 双山 | |
| Total power capacity | KVA | 7 | 11 |
| Machine dimension (LxWxH) | mm | 1600×1100×1650 | 2200×1160×1620 |
| Net.weight (about) | kg | 950 | 1800 |
